Phoebus Energie Solar Charge Controller 12 24 40A LCD (MPPT)

Name: Reviews
Brand: Phoebus Energie
Rating: 5.0 (1 reviews)

5.0 / 5.0

1 reviews / 0 Answered Questions

Delivery Option

Enter PIN code to check delivery time

Price has been updated based on your PIN location!

M.R.P.:	₹ 6,250
Price:	₹ 5,602
You Save:	₹ 648 (10%)
	Inclusive of all taxes

Brand: Phoebus Energie

Product Code: PE/MPPT/12-24-40

Seller:Phoebus Energie

OverView

Modal N0.	PE/MPPT/12-24-40
Battery Operating Mode	12V	24V
SPV (Pmax)	700W	1.4KW
Solar input voltage (Voc max)	50 V to 100 V as per customer requirement

Indications	LED or LCD
Charging method	Preconditioning, Bulk, Flot or Equilization

Battery voltage Nominal	12V	24V
Battery voltage Preconditioning	10.5V	21.5V
Battery voltage Bulk	14.5V	29V
Battery voltage: Float	13.8V	27.6V
Battery voltage Equalisation	15V	30V
Battery type	Lead Acid ( Tubular / SMF ) Note: Li-ion and Li-FePO4 Battery solutions are also available based on requirements.
Self-power consumption	<1W
Max Charging Current	45A
Solar Reverse Protection	Provided
Battery Reverse Protection	Provided
Overcurrent Protection	Provided
Short-circuit protection	Fuse
Displayed parameters on LED	Battery Reverse Polarity, Solar Reverse Polarity, Battery Charging
Displayed parameters on LCD	PV voltage, PV current, PV power, battery voltage, Charging current, and cumulative solar generated power (KWH)
Switching element	MOSFT/IGBT
Efficicency	>95%
Cooling	Fan (Forced Air Type Cooling)
Cabinet Material	Metallic
Cabinet Dimensions (LxWxH) mm	280x180x100
Color	White
Operation Temperature	0°C to 50°C
FEATURES:-	High Efficiency.
→	Multiple charging stages to maintain battery gravity.
→	Protection from Battery overvoltage and Current.
→	Automatic battery selection
→	True MPPT.
→	Protection from the reverse flow of current from the battery to the panel.
→	Easy to install.
→	Eco Friendly.
→	Wall mounting.

Questions And Answers

Please login to ask a question!

Seller	Minimum Quantity	Price	Action

Tags Solar Charge Controller 12V 24V 40A MPPT MPPT Solar Charge Controller Solar MPPT Charge Controller MPPT

Product Description

The Phoebus Energie Solar Charge Controller is a solar energy management powerhouse. Model PE/MPPT/12-24-40 provides efficient charging for 12V and 24V batteries, with SPV (Pmax) capacities of up to 700W and 1.4KW, respectively. Its cutting-edge Maximum Power Point Tracking (MPPT) technology optimises solar input voltage (Voc max) between 50 volts and 100 volts, allowing it to react to changing energy demands. Preconditioning, bulk charging, floating, and equalization are all charging procedures that ensure battery performance under all conditions. It provides unparalleled compatibility by supporting both lead-acid and Li-ion/Li-FePO4 battery systems. LED/LCD indicators give real-time information, while protections such as Solar Reverse, Battery Reverse, overcurrent protection, and Short Circuit Protection assure system durability. It's a strong and sustainable alternative for your solar setup, with over 95% efficiency, a metallic cabinet, and an eco-friendly design.
